Friday, August 31, 2012

LEICA M MONOCHROME BECOMING AVAILABLE IN THE US




Leica Dealers report that the first shipments of the Leica M Monochrom have been made.  Initially the camera will be available in only very limited quantities, but it is hoped that supplies will increase as time goes on.



To learn more about the Leica M Monochrome, go to:

ISO TEST: LEICA M MONOCHROME vs. LEICA M9

LEICA M MONOCHROM - EVALUATIONS AND COMMENTS

MONOCHROME SENSOR - WHAT IS THE DIFFERENCE

COMPARISON LEICA M MONOCHROM vs. LEICA M6

M9 M - INCREDIBLE PERFORMACE PROOF

THE LEICA M9 MONOCHROM



Tuesday, August 28, 2012

LEICA 180mm F/3.4 APO-TELYT-R



The 180mm f/3.4 Apo-Telyt-R reached the market in 1975.  At that time it was no longer a secret that Leica had developed the lens for the US Navy as part of a high resolution 35mm camera system.

The system used Leicaflex SL2 cameras, the standard 35mm Summicron-R, a 75mm f/2 Elcan-R, a 180mm f/3.4 Elcan-R (later reincarnated as the Apo-Telyt-R), and a 450mm f/5.6 Elcan-R.  This system was used by the US Navy starting in the early 1970s.


One of the problems of lens design is accurate color correction and the Navy presented Leica with the problems of developing lenses that could focus more than just the visible spectrum accurately.

Even today, most of the photographic lenses have what is referred to as “primary color correction,” where only part of the visible spectrum is focused at any time.

The solution to the problem lay in the development of glasses with what are considered “anomalous” properties; the combination of high refracting indexes with low dispersion.

Such properties are found in artificially grown crystals; an example is the calcium fluoride elements made famous in the Canon FL series telephoto lenses.

But such crystals have a very large temperature coefficient, and elements made from them are both brittle and extremely soft.  The temperature related expansion of calcium fluoride elements is so great that most lenses made with them are subject to changes in focal length with temperature changes, and therefore have no proper infinity stop or distance markings.

The softness of the material also leads to design constraints.  For instance, the Canon 300mm FL lens has a thin, conventional glass element in front of the “front” calcium fluoride element, primarily for protective purposes.

Not an ideal situation.  Lenses made of these crystal elements demand extreme care to assure proper performance, and the military considered them incompatible with the kind of treatment they were likely to receive.

The glass research lab in Wetzlar set out to develop a glass that had the optical properties of crystals like calcium fluoride, but without the negative side effects.  They did indeed develop such a glass, today commonly referred to as “apo glass.”  It was/is used in a variety of Leica lenses, including the Apo-Telyt, the 800mm Telyt-R, and the Noctilux 50mm f/1.  Their designer, Dr. Walter Mandler, was the man whose genius brought us those lenses, but also the 35mm Summilux, and close to fifty other lenses for Leica cameras, in addition to lenses for RCA television cameras, IMAX projectors, and Picker X-ray equipment.


How good are the Elcan lenses, specifically the Apo Telyt 180mm f/3.4?  While most photographic lenses have a color correction from 400 to a maximum of 700 nanometers, the Leitz apo glass allows correction up to 900 nanometers.  In simple terms, this means that all colors of the visible spectrum and infrared are focused in a single plane.

The Apo-Telyt proved to be the best lens of the set, making it one of the very few lenses for 35mm cameras that do not require refocusing when used with infrared films or sensors.

The US Navy conducted comparison tests with the 180mm f/2.8 Elmarit-R.  These demonstrate the effects of the apochromatic correction of the Apo-Telyt.  Both lenses were tested at f/3.4 with blue, yellow-green, red and infrared light.  The maximum focus shift of the Apo-Telyt was +/- 0.045mm.  The shift of the 180mm f/2.8 Elmarit-R (at f/3.40 was +/- 0.25mm.

In practical applications, such correction translated into fantastic sharpness.  Increased resolution is readily apparent, made possible by greatly increased contrast capabilities.

The Navy test showed that the Kodak 5069 film, developed in H&W 4.5 developer consistently achieved resolution figures of 600 lines per millimeter.  To make enlargements with this kind of detail required a specially modified Leitz Focomat II enlarger and lenses.

It is safe to say that regardless of manufacturer, the Leitz Apo-Telyt-R 180mm f/3.4 is still one of the very best lenses ever made for 35mm photography.


For more on the subject go to:

The Leica Camera Blog
Carl Merkin: The spy Who Came In From The Cold…The 180mm f/3.4 Apo-Telyt-R

MANUFACTURE AND PERFORMANCE OF PHOTOGRAPHIC LENSES
This article has a lot more information on the Apo-Telyt and the tests conducted by the US Navy.

In Memory of the LEITZ GLASS LABORATORY

OPTICAL GLASSES




ANSEL ADAMS




Some readers might wonder why Ansel Adams is the topic on the LEICA Barnack Berek Blog.  After all, as far as we know, among the large number of cameras he has worked with, a Leica was never one of them.

As Leica enthusiasts, we sometimes have a tendency to get too wrapped up in our equipment.  The fact that Ansel Adams apparently never did any work with Leica equipment in no way diminishes his accomplishments.  To the contrary, all photographers, including Leica owners, can learn a lot from him.  His approach to photography with the Zone system, which he created, is still as much up to date today as it was when he worked his magic with black and white photography.  This is part of what makes him of great interest to the Leica community, because Leica these days has probably a much wider number of followers still using analog photography than any other camera out there.  By applying his techniques, I have certainly been able to produce better black and white photographs than I would otherwise have been able to.



Ansel Adams at work

This is not going to be an article on Ansel Adams’ camera and darkroom techniques.  For that he is doing a much better job in his books than I ever could.  Instead this is a remembrance of one of the giants of photography, an individual that will forever be remembered as one the absolute masters of his craft.

The L-Camera blog has published a two part video of Ansel Adams from 1958.  In this 20-minute presentation you get an insight into his working methods, his own interests and attitude to art,  and his gigantic amount of camera equipment.

You will accompany the photographer through the entire process of analog photography, from the precise light reading of the object, the correct exposure settings of the camera and onto  the right development of the photos in the darkroom.

But you will also see another, much lesser known side of Ansel Adams, that of an accomplished pianist.  As a matter of fact, he initially planned to become a concert pianist, but the onset of arthritis kept him from doing so.  It wasn't until then that he began his career as a photographer.

The piano music accompanying the video was all played by Adams.  Listening to it is a captivating opportunity to see the other artistic side of this great artist.

I am showing only one example of his work.  It is almost impossible to make a reasonable selection from his many published photographs.  This one stands out because it was taken without the possibility of an exposure reading.  He came upon this scene while driving home from an assignment.  The light was changing quite rapidly and Adams had barely time to set up his camera and tripod.  It is to his credit to be able to accurately determine the exposure simply based on experience.


Moonrise over Hernandez



For the video go to:



Sunday, August 26, 2012

“RICHTER” LEICA III


By Heinz Richter

I think every Leica enthusiast remembers the Leica camera that ‘started it all’. I am one of the fortunate individuals that can truly say that I have used Leicas all my life, well, almost.

I grew up in the photography business of my father in Germany. This naturally exposed me to photography and cameras at an early age. It was always my father's dream for me to take over the business once he retired. That, however, does not mean that I was pushed in that direction, to the contrary, I was always encouraged by my parents to follow my own interests, of which there were many. But my dad also always encouraged me to take pictures of my own. I must have had some noticeable interest, because on my fifth birthday he presented me with my Leica No. 1, a Leica III with 50mm f/2 Summar and a Steinheil Culminar 135mm f/4.5. That also included a Braun Viewfinder, adjustable from 35mm to 135mm and a Leitz VACU flash synchronization device.


Leica III with Summar 50mm f/2

Leica III back with Foto Richter Barntrup Nameplate

Leica III with Summar 50mm f/2 and FIKUS Lens Shade

I am convinced that starting out with this camera ultimately made me a better photographer for a variety of reasons. My dad did not give me a light meter, instead he taught me the sunny 16 rule and for flash, there was never any automation until much later in my life. I simply focused and then had to use the old guide number divided by distance formula to determine the aperture setting. Considering that I also had to deal with a collapsible lens, I had ample opportunity to make mistakes, and mistakes I made, many.

After wondering about some very blurry images, even though I knew I had focused my lens quite carefully, and after many explanations from my dad, I eventually remembered to pull out the collapsible lens before I started shooting. I also soon figured out that taping a little guide in back of the flash with the guide number/distance formula eventually lessened flash exposure mistakes, as did a note with the sunny 16 exposures on it.

Steinheil München Culminar 135mm f/4.5

My Laica III with 50mm Summar 50mm f/2,
FICUS Lens Hood, Braun Universal finder and VACU Flash Synch


This isn’t meant to give me a pad on the back. I truly believe that starting out totally manually made photography in the long run a lot easier for me. Even though I have since switched to digital Leica equipment, I still use film occasionally, for no other reason than not to lose my touch. To this day I have no problem getting correct exposures without the help of a meter. As a matter of fact, once I did start using a light meter, it gave me cause to explore what these instruments are capable of beyond just plain camera settings.
Even now, working in my studio or doing architectural and other photography, I still rely very much on my light meters. Even in these days of Photoshop, I still approach my photography as in the film days. That includes careful light readings and all else that I can do to get the shot right. That certainly makes post production a lot less time consuming because generally, I don’t have to correct for mistakes.
Having grown up with rangefinder cameras, which of course included the use of add-on viewfinders, never bothered me. I have owned several of the Leica R models, but inevitably I always gravitate back to the rangefinder Leicas. This is also the reason why I am hoping for an electronic add-on finder for the upcoming M10 or whatever the M9 replacement is going to be called. It is my belief that this would make the M10 (let’s just call it that) a true system camera. Without the electronic viewfinder it could be used with the typical M lenses from 28 to 135mm and the electronic finder will then be substituted with all the other lenses that do require a separate finder. But in addition, this would greatly enhance the versatility of the camera since the electronic finder would also allow for virtually unrestricted close up photography as well as the use of long telephoto lenses. This could also be the answer for all the Leica R lens owners who, for a long time, have waited for a digital camera to use their R lenses on.
Thus my good old Leica III from so many years ago has effectively been the starting point in a long succession of cameras which, with the exception of the R models I have owned, have been further developments of the Leica III which, in itself, is essentially nothing more than a further development of Oskar Barnack’s Ur-Leica prototype. No other camera anywhere can look upon such a long history and no other camera ever will.





Monday, August 20, 2012

LEICA CAMERA: EINDRUCKSVOLLE FOTOKUNST AUF DER PHOTOKINA 2012





Please use the TRANSLATOR at the top right to get the LEICA press release in your language

Solms (ots) - Mit einem einzigartigen Ausstellungskonzept ist die Leica Camera AG in diesem Jahr auf der Photokina in Köln vertreten. In Halle 1 präsentiert Leica vom 18. bis 23. September 2012 die Aufnahmen international bekannter Fotografen - und macht Fotokunst für Besucher der Photokina zu einem eindrucksvollen Erlebnis. In Halle 1 der Kölnmesse wurde bis zur vergangenen Photokina die "Visual Gallery" präsentiert.

Unter den Ausstellungen sind die Serien "Portraits of Power" von Platon,"Arab Spring" der Magnum-Fotografen Dominic Nahr, Thomas Dworzak und Moises Saman und Aufnahmen des renommierten Projektes "Facing Change Documenting America" von Anthony Suau.

Darüber hinaus präsentiert Leica erstmals die Ausstellung "Personal Best for Leica" von Magnum-Fotograf Elliott Erwitt sowie Aufnahmen von international bekannten Fotografen wie Araki, Rankin, Andreas Gursky und Hubertus von Hohenlohe.

Die Ausstellungen werden von Karin Rehn-Kaufmann, Inhaberin der Leica Galerie Salzburg, und Inas Fayed, Chefredaktion Leica Fotografie International (LFI), kuratiert. "Zur diesjährigen Photokina bieten wir allen Besuchern neben Produkten vor allem eindrucksvolle Fotokunst. Das von uns entwickelte Konzept der Ausstellung ordnet die Bilder aller namhaften Fotografen thematisch einzigartig ein. Durch eine individuelle Farbgebung der Ausstellungswände wird die Bedeutung jeder Ausstellung hervorgehoben und damit ansprechend präsentiert", so Karin Rehn-Kaufmann.

Zahlreiche der Fotografen, deren Bilder Leica in diesem Jahr präsentiert, sind zudem persönlich auf der Photokina und geben Besuchern Einblicke in ihr Werk. Besucher können die Fotografen vom 18. bis 23. September 2012 täglich ab 11 Uhr auf der Leica Bühne erleben.





Saturday, August 18, 2012

LEICA 1st QUARTER FINANCIAL REPORT



Leica holds its ground


Against the background of compact camera sales figures on the world market dropping by more than 20 % Leica Camera AG was able to hold its ground in the first quarter of fiscal year 2012/2013. The first quarter of the current fiscal year closed with sales of € 71.7 million (corresponding period last year: € 72.3 million). This corresponds to a slight decrease of 0.8 % as compared to the same period of the previous year. The operating result (EBIT) after the first quarter amounts to € 15.3 million (corresponding period last year: € 16.5 million). The EBIT margin decreased thus by 1.4 % to 21.4 %.

As a result of new product launches as well as the opening of sales offices (among others in Tokyo, Washington, D.C and Shenzen, China) and the establishment of an own distribution organisation in Italy total assets rose to € 205.3 million (corresponding period previous year: € 163.4 million).

Due to a large number of new products, among them the Leica M Monochrom launched in May 2012, Leica X2 and Leica V-Lux 40 as well as the APO-Summicron-M 1:2 50mm ASPH., the order intake has surpassed the Company’s expectations and has led to a high utilisation of production capacity. This positive development resulted in higher material costs in the first quarter of the fiscal year, whereas delivery of the majority of products will be effected in the second quarter. As a result of the order situation personnel expenses have increased as well. The number of employees has increased to 1,257 as of June 30, 2012 (1,152 as of June 30, 2011).

The Company was already able to record sales increases in the first quarter for the strongly requested M lenses and the new Leica X2. In a highly competitive market the sales of the Sport optics division are 1.3 % above the previous year’s period. This is mainly due to the new Magnus riflescopes.

Regionally Leica Camera AG was able to increase sales by more than 5 % in the USA and Asia as compared to last year’s period, whereas in Europe a slight decline of sales had to be recorded.
During the course of the current fiscal year, particularly after the start of delivery of the products high in demand, the Board of Management expects a sales increase as compared to the previous year as well as positive consequences for the operating result.

Solms, August 17, 2012
The Board of Management
Alfred Schopf, Ruud Peters, Markus Limberger






Friday, August 17, 2012

WIN A LEICA M MONOCHROM




Black + White Photography made the following announcements:

Move over Kate Moss, see you later Cindy Crawford, vamos Naomi Campbell - a real supermodel has arrived at last.

Meet the exclusive Black+White Photography Leica M Monochrom!

If you manage to stop drooling for long enough this beauty could be yours. Enter Black+White Photographer of the Year 2012 to be in with a chance.

Well this Tuesday afternoon just got a whole lot more magical!

Leica have sent us the first images of our exclusive (as in no one else in the world will ever have one!) Leica M Monochrom with its lovely lens attached.

For your chance to win the engraved model, visit bpoty.com and let the monochrome mayhem begin! Sorry, we might be a little bit overexcited...

See bpoty.com for more info.








Wednesday, August 15, 2012

IS THIS THE OTHER UR-LEICA?




We have seen pictures of the Ur-Leica on numerous occasions, as a matter of fact, it has become quite familiar to many of us.  We also know that this is the camera that Oskar Barnack gave to Ernst Leitz I.  We also know of a second, identical model, which is the one that Barnack used himself.  It had been in the possession of his son, who ultimately sold it and all traced seem to be lost.  However, it is assumed that this camera resides these days in an unidentified collection.

Today I came across a picture of a camera that obviously is the, or should I say, a Ur-Leica.  At first glance it looks identical, but upon closer inspection, the camera is different.  The most visible difference is the bare spots on the upper left side of the camera, where the original black paint is chipped off.  In addition, there are several other cosmetic differences.

We know that the Ur-Leica that is in possession of the Leica Camera AG has never been restored.  On the other hand, this could possibly be a photograph of the same camera from earlier days.

There was no information that accompanied the picture I came across today, but it is intriguing to compare pictures.  It is definitely not a picture of one of the replica Ur-Leicas.  This photograph was made prior to 1952.  One cannot help but wonder if we are looking at the two original Ur-Leica cameras.

The other Ur-Leica?

A picture of the known Ur-Leica from a similar angle.
Note the worn off , chipped paint


Additional pictures of the Ur-Leica for comparison


Postscript 4-07-2013

This article was written, based on the published information regarding the development of the Leica.  Further research has shown that this generally accepted and published information contains several mistakes.  These are pointed out and corrected in the following article:

THE REVISED HISTORY OF THE LEICA





Tuesday, August 14, 2012

ANNIVERSARY OF A VERY FAMOUS LEICA PHOTOGRAPH




It was 67 years ago that Alfred Eisenstaedt took this iconic photograph of a sailor kissing a nurse with his Leica on V-J Day in Times Square in New York City.


After decades of dispute, the couple in the 1945 photograph were revealed to be 89-year-olds George Mendonsa and Greta Zimmer Friedman.

Now the couple who won the nation's heart, reunited in the location of the famous smooch to reflect on the photograph that came to symbolize the end of the war.

'It was the moment. You come back from the Pacific, and finally, the war ends,' Mendonsa told CBS.

Mendonsa told how he was on a date with another woman named Rita Petry at Radio City Music Hall on August 14 when news of the Japanese surrender was announced.
'They stopped the show and they said, "The war is over. The Japanese have surrendered,"' he recalled.

Mendonsa spotted a woman in a nurse’s uniform - he left Petry and rushed to grab her.

'The excitement of the war being over, plus I had a few drinks,' he told CBS. 'So when I saw the nurse, I grabbed her, and I kissed her.'

'I did not see him approaching, and before I know it, I was in this vice grip,' Friedman added.

That moment was so eloquently captured by LIFE photographer Alfred Eisenstaedt.





Monday, August 13, 2012

BLACK AND WHITE FILM PHOTOGRAPHY




There should be no doubt that digital photography has conquered the world.  But that does not mean that traditional, analog photography is dead.  Especially for Leica owners, the use of film is still an important aspect of photography because many of the pre-digital Leica cameras are still in daily use.

Unfortunately, many of the old film manufacturers are no longer with us.  Great names like Kodak and Agfa have long since all but disappeared from the market.  The most common names of film manufacturers today are Ilford and Fuji.  That makes it all the more amazing to see the resurrection of one of the oldest and highest regarded names in black and white photography to reappear.


ADOX


This is one of the world´s oldest brands for photochemical products.  ADOX was founded as the world’s first photochemical factory in 1860.  The  ADOX Dr.C Schleussner GmbH soon became one of the leading producers in Europe.  Legendary films such as the KB 14 and KB 17, being the world´s first thin layer films, made ADOX famous all over the world.  In the USA KB 14 and KB 17 were called "the German wonder film".



ADOX Fotowerke Dr. C. Schleussner GmbH

Small coating machine

Goebel Super1400 Filmslitter
This machine is still in the posession of ADOX Fotowerke GmbH and runs up to today

ADOX disappeared from the photographic market many years ago and the name became part of photographic history.  In recent years some of their products reappeared under the name of Efke, made by Fotokemika d.d, a company located in Samobar, Croatia.

Through the efforts of Fotoimpex GmbH, the ADOX name has returned to Germany.  ADOX takes on the challenges of the new market for traditional photographic products by building the "smallest photochemical factory in the world" in Bad Saarow close to Berlin, Germany.  The small factory enables ADOX to manufacture a wide variety of materials in small lot sizes while keeping overhead costs down.

Their main films are the ADOX® CHS 25 • CHS 50 • CHS 100 Films.   These films are old school emulsions which are still produced according to the old ADOX formulations which were introduced in the 1950ies.  For years they have been selling this film under the Efke label, but now it gets back its original name: ADOX. They claim that by using ADOX CHS films your view on the world is the one of the 50ies and 60ies, something that should go along quite well with many of the Leica lenses of that time.  These films have a great tonal range and color separation.  They modulate differently from modern films.  ADOX CHS films have their own feel and look to them.  Especially when pictures are dominated by blue sky the areas in the sky produce a very nice darker grey compared to more modern films giving the images a different depth and look.

ADOX CHS 25 35mm Film

These films were introduced by ADOX in the 1950ies and quickly became the preferred films for reporters.  The films have an ultra high silver content enabling it to produce the richest grey scales and many tonal differences between black and white.

If developed in sharp working developers such as ADOX ADONAL, a faithful resurrection of the famous Agfa Rodinal, the films develop a visible edge effect and very high acutance and detail.

Because of their low diffusion single emulsion layer technology the films are ultra sharp compared to modern multi layer films where the light will be diffused when penetrating through the different emulsion layers.

CHS stands for Cubiccrystal Heterodispers Single- Layer, which means the emulsion is made up of classic cubic silver halide crystals which are mixed in different sizes and coated in one layer.  The 25 speed film is the finest grain film with a classic behavior of low speed films.  This means for example the film is hardly influenced by under exposure or reciprocity effects but can´t cope with over exposure because it can´t shield itself from too much light  Also, its latitude is not as wide as those of faster films.

For beginners ADOX recommends the ADOX CHS 50 or 100.  The 50 has almost the flexibility of the 100 yet almost as fine a grain as the 25.

This makes the ADOX 50 the preferred film.  It has finer grain and better tonalities than modern 100 ASA films, yet almost the same effective speed in certain developers.

The CHS 100 is the highest speed film which can be made based on this old technology. In the 1950ies it was called a „high speed film“.  Being the fastest film it has the widest exposure latitude and contrast range but also develops the largest film grain out of the ADOX family.  So especially with this film you might want to use ADOX ATM49 developer because it will yield a much smaller grain than Rodinal or APH09.

If you use Pyro developers the ADOX CHS 100 can reproduce almost one full additional tonal zone compared to more modern films.  This makes it an excellent sheet film as grain does not matter so much in a large format.

ADOX films are supplied as KB, 120 and sheet films. They even produce strange film sizes like 127 or re-sized 620.  All roll films (120 films) are supplied in dustproof light protecting black plastic containers.

CHS 35mm and 120 Films are being coated on clear PET. Therefore the films are sensitive to light penetrating through the film base, fogging the emulsion. They sell all 35mm and 120 films in black plastic containers.

CHS 25 is the finest grain film from the historical ADOX CHS film range.

Because of the cut off in spectral sensitivity at about 620nm red image tones tend to be converted to a darker grey compared with modern superpanchromatically sensitized films.
This leads to a better separation of lips from white skin in portrait photography and makes the use of a green filter obsolete.  The speed gap between blue and green/red gives you interesting skies with better separated clouds (comparable to a soft yellow filtering of modern films).

If developed in ADONAL/RODINAL or Neofin Blue CHS 25 becomes ultra sharp and brilliant.
Grain is usually not a problem with CHS 25 because of its fine grain low speed emulsion so this group of developers can often be preferred over equalizing developers such as ATOMAl 49 / D76 etc.

Low speed films need to be exposed for the highlights and developed for the shadows (which is the opposite as for high speed films).


An entirely new product is the ADOX CMS 20, the sharpest, most fine grained and highest resolving image recording system in the world.  These films require to be developed in ADOTECH developer, they cannot be developed in regular developers.

No other film is sharper, no other film is more fine-grained, no other film resolves more lines per mm (up to 800 l /mm).

ADOX CMS 20 Films

If used in pictorial photography the film achieves 20 ASA of usable speed in ADOTECH developer.  If used for high contrast purposes the usable speed increases to 80 ASA. If developed in non dedicated low contrast developers (HC 110, Cafenol etc) it can be exposed at 3-6 ASA.

However, ADOX does not recommend using a different developer and they cannot guarantee the results.

The film developer combination CMS 20 plus ADOTECH has been brought to perfection in years of research.  The film achieves grain free enlargements of up to 2,5 meters diagonally.  This equals mathematical about 500 Megapixel. 12 Megapixel  equal 2,4% of 500 Megapixel.

ADOX CMS 20 enlarged from 35mm

ADOX CMS 20 enlarged from 35mm

Cropped very small section of the above full frame image

The special monodisperse ultra high resolution emulsion of the film makes it possible.  The AHU anti halation layer in between emulsion and base material guarantees sharpness yet preventing any halation effect.

ADOTECH developer brings perfect halftones and increases the speed to 20 ASA and creates images no one would possibly believe to have been made with a 35mm camera.

ADOX CMS 20 has an orthopanchromatic sensitivity which differentiates perfectly between colors. The CMS “sees it all“.  No green filter is necessary in portrait photography.

The film´s base is totally transparent making it theoretically possible to reverse it and use it as an ultrahigh resolution slide film with extreme projecting possibilities.  In order to do so you need to combine a reversal process with Adotech as a first developer.

Think you can´t shoot at 20 ASA?  ADOX gives the following explanation:

“If you want high resolution pictures you need to open your lens aperture to one stop below maximum opening.  Otherwise the lens diffraction will lower your lens' resolution down to half of what this film can capture.  Best lenses are F1,4 high speed high quality lenses like Leica Summilux lenses.  This puts you effectively between F2 and F4.

Any normal day 2 hours after sunrise and up to two hours before sunset will give you something like a 125th or a 250th of a second at F 3,5.  Therefore the film can be used under almost any condition where it makes sense to use it because there is actually something to see.
More speed would force you to stop down too much on a sunny day, letting slip what your lens can actually achieve.

In bad light conditions the film makes no sense because you barely see something so you might as well use a lower resolving film to capture this.  Basically, you can shoot everyday with this film unless the sun is gone or behind heavy clouds or you want to shoot indoors without a flash.”
